KCMS125EWH0 04 – DOOR AND LATCH

Products

PositionProduct
14313105 Whirlpool Microwave Switch
24392027 Whirlpool Microwave Primary Switch
4Latch Lever
5Latch Hook
6SCREW
7Choke Cover
8Latch, Door
9Spring, Latch
10Holder, Fuse
12Door, Complete (Stainless)
12Door, Complete (White)
13Frame, Door (Stainless)
13Frame, Door (White)
14Support
15Panel, Door
16Screen, Door
