KEBI170SBL0 07 – CABINET

KEBI170SBL0 07 – CABINET

Written by

in

KEBI170SBL0 07 – CABINET

Products

PositionProduct
WPL 3050282
WPL 3050292
1Main Bottom KESO-140/145, KEDO-240/245
2Main Bottom KESO-170/175 KEDO-270/275
3Insulation, Bottom KESO-140/145, KEDO-240/245
4Insulation, Bottom KESO-170/175, KEDO-270/275
5Door Gasket KESO-140/145, KEDO-240/245
6Door Gasket KESO-170/175, KEDO-270/275
7Front Frame, Lower Oven KEDO-240
8Front Frame, Lower Oven KEDO-245
9Front Frame, Lower Oven KEDO-270
10Front Frame, Lower Oven KEDO-275
11Bottom Trim KESO-140/145, KEDO-240/245
12Bottom Trim KESO-170/175, KEDO-270/275
13Hinge Arm Guide
14Cover – Seal End
15Oven Liner (Lower Oven) (See Page 10)
16Insulation, Top and Sides
18Compartment Top, Lower Oven KEDO-240
20Compartment Top, Lower Oven KEDO-275
21Knob, Latch Lever
22Latch Assembly (See Page 8)
23Insulation, Rear KESO-140/145, KEDO-240/245
24Insulation, Rear KESO-170/175, KEDO-270/275
25Rear Anchor
26Cabinet Side – Lower Oven KEDO-240
27Cabinet Side – Lower Oven KEDO-245
28Cabinet Side – Lower Oven KEDO-270
29Cabinet Side – Lower Ov
30WPL CC20049
31WPL CC20050
32WPL CC32307
33WPL CC71633
34WPL CC32424
35WPL 3052392
36WPL 3052391
37WPL ARI82728A4
38WPL CC31733
39WPL CC31734
40WPL CC32192
41WPL CC32191
42WPL CC31866
43WPL CC32223
44WPL CC32224
45WPL CC32207
46WPL CC32206
47WPL CC32210
48WPL CC32209
49WPL CC70863
50WPL 3052481
51WPL 3052484
52WPL CC22045
53WPL CC32220
54WPL ARI82729A3
55WPL 3053511
56WPL CC32284
57WPL CC22044
58WPL CC22126
59WPL CC22100
60WPL CC22143
61WPL BL27
62WPL CC566083
63WPL CC22022
64WPL CC71041
65WPL 305104
66WPL CC19760
67WPL CC71196
68WPL CC31876
69WPL 3050281
70WPL 3050291
71WPL CC71194
72WPL CC22058
73WPL CC606517
74WPL CC606518
75WPL CC22049
76WPL CC22054
