KEBS177XAL1 04 – COMPONENT SHELF AND LATCH

Products

Position	Product
1	Shelf, Component
2	WP8203546 Whirlpool Terminal Block
2	W10841059 Whirlpool Screw
3	Bushing
4	Switch, Latch
5	Insulator, Switch
6	Guard, Latch
7	Handle, Latch
8	Knob, Latch Handle
8	Screw
9	Spacer, Handle (2)
9	Screw (2)
9	Screw, 8-18 X 3/4 (4)
10	Latch, Mechanism
11	Plate, Mounting
12	Plug, Button
13	WP90767 Whirlpool Screw
13	Extension, Shelf
14	Support, Latch
14	WP488234 Whirlpool Air Conditioner Screw
15	Bracket, Buzzer
15	Screw,
16	Buzzer, Meat Probe
16	Screw
17	Transformer
17	WP3177991 Whirlpool Screw
18	Switch, Latch
18	Screw (2)
