KEBS277WBL2 02 – CONTROL PANEL, LIT/OPTIONAL

Products

Position	Product
	WPL LIT3177060
	WPL LIT3178195
	Cookbook
	WPL LIT3178200
	WPL LIT4174135
1	Thermostat, upper
2	Backlight (2)
3	Switch, Selector
4	Indicator Light, Oven (Lower Oven)
5	Switch, Oven Light (White)
5	Switch, Oven Light
6	Nut, Timer (4)
7	Insert, Top (Almond)
7	Insert, Top (White)
7	Insert, Top (Black)
8	Bracket, Control
9	Timer, Electronic
10	Glass, Control Panel (White)
10	Glass, Control Panel (Almond)
10	Glass, Control Panel (Black)
11	Frame, Control Panel (White)
11	Frame, Control Panel (Almond)
11	Frame, Control Panel (Black)
12	Insert, Vent
13	Knob, Clock
13	Knob, Timer (2)
14	Knob, Timer
14	Knob, Clock (2)
15	Door, Latch Handle (Almond)
15	Screw (5)
15	White
15	Handle (Black)
16	Knob, Control
17	Disc, Selector (Lower)
17	Disc, Selector (Upper)
18	Disc, Thermostat (Self Clean)
19	Meat Probe Indicator Assy.
20	nut (3)
21	Door, Latch Handle (Screw (2))
21	Hinge, Door (2)
22	Retainer
22	Screw (6)
23	Thermostat, Upper
24	Bracket, Control Panel
25	Bezel, Oven Light Switch
25	Bezel, Switch (White)
26	WP3177991 Whirlpool Screw
26	Support, Frame
27	WP486579 Whirlpool Air Conditioner Screw
27	Screw,
27	Switch, Selector
29	Switch, Rotory
30	Knob
30	Clip, Spacer
