KEBS277XAL3 08 – COMPONENT SHELF AND LATCH

KEBS277XAL3 08 – COMPONENT SHELF AND LATCH

Written by

in

KEBS277XAL3 08 – COMPONENT SHELF AND LATCH

Products

PositionProduct
1Shelf, Component
2WP8203546 Whirlpool Terminal Block
3Bushing
4Switch, Latch
4Screw
5Insulator, Switch
6Guard, Latch
7Handle, Latch
7WP90767 Whirlpool Screw
7Handle, Latch
7Handle, Latch (Screw (2))
8Knob, Latch Handle
8Screw
9Spacer, Handle (2)
9Screw (2)
10Latch, Mechanism
11Plate, Mounting
12Plug, Button
13Extension, Shelf
14WP488234 Whirlpool Air Conditioner Screw
14Support, Latch
15Bracket, Buzzer
15Screw
16W10841059 Whirlpool Screw
16Buzzer, Meat Probe
16Screw,
17Transformer
17WP3177991 Whirlpool Screw
18Screw (2)
18Switch, Latch
