KEBS277XWH0 06 – UPPER AND LOWER OVEN DOOR

Products

Position	Product
1	Screw, Black (2)
1	Liner, Door
2	Seal, Window
3	Spacer, Window
4	Latch, Strike
5	Insulation, Retainer
7	Glass, Door (Black)
7	Glass, Door (Almond)
7	Glass, Door (White)
8	Glass, Reflective
9	Frame, Door
10	Handle, Door (White)
10	Handle, Door (Black)
10	Handle, Door (Almond)
11	Screw
11	Spacer (2)
11	Spacer (2) (Almond)
11	Spacer (2) (White)
12	Bracket, Glass Mtg.
12	WP90767 Whirlpool Screw
13	Window Package
14	Insulation, Door
15	Bushing, Door Handle
16	Bumper, Door Glass
