| Tape, Foam (67``) |
| USE & CARE GUIDE |
| Installation Instructions |
| Hardware Assembly |
| 1 | Switch, Infinite (Use W/1400W Left Rear Burner) |
| 2 | Seal, Inifinite Switch |
| 3 | Seal, Switch Shaft (2) |
| 4 | Element, Grill (240 Volt) |
| 4 | Element, Grill (204 Volt (opt.)) |
| 5 | Top, Burner Box (Black) |
| 5 | Top, Burner Box (White) |
| 5 | Top, Burner Box (Almond) |
| 6 | Light, Indicator (2) |
| 7 | Grate, Grill (Black) |
| 7 | Grate, Grill (Stainless Steel) |
| 8 | Side, Burner Box (2) |
| 9 | Bracket, Terminal Block (2) |
| 10 | Bracket, Control Panel |
| 11 | Bracket, Wireway |
| 12 | WPL 312318 |
| 12 | Bottom, Burner Box |
| 12 | Screw, |
| 14 | 8186533 Whirlpool Hardware |
| 14 | Screw |
| 14 | Nut, Tinnerman (2) |
| 14 | WP488729 Whirlpool Refrigerator Door Screw |
| 15 | Knob, Cooktop (Black) |
| 15 | Knob, Cooktop (White) |
| 15 | Knob, Cooktop (Almond) |
| 16 | Trim, Extrusion (Black) |
| 16 | Trim, Extrusion (Almond) |
| 16 | Trim, Extrusion (White) |
| 17 | Pan, Grill |
| 18 | Screen Basket Assy. (Lava Rocks Included) |
| 19 | Clip, Terminal Block (5) |
| 19 | 303776 Whirlpool Dishwasher Screw |
| 20 | Block, Terminal |
