KECT025YAL0 02 – SECTION

Products

Position	Product
	Use & Care Guide
	Repair Parts List
	Installation Instructions
1	Cooktop, Glass (White)
1	Cooktop, Glass (Black)
1	Cooktop, Glass (Almond)
2	WP486579 Whirlpool Air Conditioner Screw
2	Switch, Inifinite (Front Burner (Green Shaft))
2	Switch, Inifinite (Rear Burner (Orange Shaft))
3	seal, element
3	WPL 3179362
4	Seal, Inifinite Switch
5	Seal, Switch Shaft (2)
6	gasket, ring (2.0 KW)
6	gasket, ring (1.5 KW)
7	8203517 Whirlpool Oven Surface Element
7	Element, Solid (Rear Burner)
8	bracket, element (1.5 KW)
8	bracket, element (2.0 KW)
9	Thermostat (2)
10	Spring, Leaf
11	hex nut (8)
12	Nut, Metric
13	Knob, Cooktop (White)
13	Knob, Cooktop (Almond)
13	Knob, Cooktop (Black)
14	seal, foam tape
15	Screw, 8-32 X 1 1/2
15	8186533 Whirlpool Hardware
15	Screw (4)
15	Nut, Tinnerman (2)
15	Screw
16	Top, Burner Box
17	Side, Burner Box (2)
18	Bottom, Burner Box
19	WP488729 Whirlpool Refrigerator Door Screw
19	WPL 312318
19	Bracket, Control Panel
20	Light, Indicator (2)
21	Trim, Extrusion (Black)
21	Trim, Extrusion (Almond)
21	Trim, Extrusion (White)
