KEDS100VAL0 05 – COOK TOP , LIT/OPTIONAL
Written by
in
KEDS100VAL0 05 – COOK TOP , LIT/OPTIONAL
Products
Position
Product
Wire (14 Ga. 150 c Yellow)
console
Wire (12 Ga. 150 c Black)
18 Ga. 80~c Rating (Red)
Wire (14 Ga. 200 c Brown)
1
WPL LIT3147430
Rotisserie Kit
Grease
WPL LIT3148391
Cookbook
WPL LIT884386
Wire (14 Ga. 150 c Orange)
Wire (14 Ga. 150 c Green)
FOIL, ALUMINUM OVEN (18“ X 25 )
Instructions, Installation
Wire, 25` Roll (Black 14 Ga.)
Wire, 25` Roll (Red 14 Ga.)
Wire, 25“ Roll (White 14 GA.)
Touch-Up Oven (1 Oz.)
242831 Whirlpool Oven Wire
Wire (14 Ga. 150 c Blue)
Wire (14 Ga. 150 c Brown)
1
Support, Box
2
Box, Burner
3
Shield, Switch
3
WP488729 Whirlpool Refrigerator Door Screw
4
Support, Cooktop
5
814103 Whirlpool Clip
6
WPL 258109
7
Cover, Top Rear
8
Cooktop (Almond)
8
Cooktop (White)
8
WPL 312318
8
Cooktop (Black)
9
WP4332752 Whirlpool Clip
10
Panel, Control (White)
10
Control Panel (Black)
10
Panel, Control (Almond)
10
Control Panel (Tape, Foam)
11
Seal, Switch Shaft (2)
12
WP486579 Whirlpool Air Conditioner Screw
12
W10900107 Whirlpool Oven Surface Element Switch
13
Indicator Light
14
Bracket, Sensor
15
Thermostat
15
WP313808 Whirlpool Screw
18
Lens, Light
19
Reflector Pan (6“ (2))
19
W10291024 Whirlpool Range Cooktop Gray Porcelain Drip Bowl Set
20
WP660532 Whirlpool Oven Surface Element
20
WP660533 Whirlpool Oven 8" Surface Element
21
Medallion (4)
22
Knob, Control (4)
23
W10858781 Whirlpool Trim Ring
23
W10854470 Whirlpool Trim Ring
26
16515 Whirlpool Clip
←
