KEDS100VAL1 03 – DOOR

KEDS100VAL1 03 – DOOR

Written by

in

KEDS100VAL1 03 – DOOR

Products

PositionProduct
1Liner, Door
2Frame, Inner
3Screw
3Seal, Flange (2)
4Glass, Reflective
5Seal, Door
6Retainer,
7WP3169203 Whirlpool Door Glass
8Retainer, Glass (2)
9Bumper (4)
10Glass, Panel (White)
10Glass, Panel (Almond)
10Glass, Panel (Black Model)
11Foil, Door
12Handle, Oven Door (Almond)
12Handle, Oven Door (White)
12WP355515 Whirlpool Screw
12Handle, Oven Door
13Insulation, Door
14Cap, Top
15Clip (2)
16Sheild, Door
18Frame (Almond)
18Frame (White)
18Frame, Door
19Back Splash (Screw (4) 10AB x 1/2“)
19Door Top (Panoramic Grey)
19Top, Door Frame
19WP308685 Whirlpool Microwave Screw
