KEDS100VAL1 04 – CONTROL PANEL

Products

Position	Product
1	End Cap. L.H. (Black)
1	End Cap, L.H. (Almond)
1	End Cap, L.H. (Almond)
1	End Cap (Washer)
1	End Cap. L.H. (White)
1	End Cap. L.H. (Black)
1	End Cap, L.H. (White)
2	Glass, Control Panel (White)
2	Glass, Control Panel (Almond)
2	Glass, Control Panel (Black)
3	Rail, Top (Bright Aluminum)
3	Rail, Top (Black)
4	Trim, Center (Bright Aluminum)
4	Trim, Center (Black)
5	End Trim, Vent (Right Side)
5	End Trim, Vent (Left Side)
5	Trim, Vent Door (Brite Aluminum, L.H.)
5	Trim, Vent Door (Brite Aluminum, R.H.)
6	Door, Vent
6	Door, Vent (Semi-Bright Aluminum)
7	Screw, 10-32 x 1/2
7	Trim, Bottom
8	Rubber Channel (2) (Black Model Only)
9	Retainer, Glass (4)
10	Bracket, Control Panel (2)
12	Bracket, Control
13	Electronic Range Control
13	Screw
17	WP313808 Whirlpool Screw
17	Thermostat, Oven
20	White Model
20	Lockwasher
20	Switch, Oven Light
21	Bezel Switch (1)
21	Bezel, Switch (White - Almond)
22	WP308605 Whirlpool Refrigerator Clamp
26	Knob, Bit Generator (White)
26	Knob, Bit Generator (Black)
26	Kno
31	Bracket, Control
32	WPL 3149781
32	WPL 3149782
32	WPL 3149780
33	Trim, End Cap (Almond)
33	Trim, End Cap (White)
33	Trim, End Cap (Black)
34	Shield, Air
35	WPL 309080
35	Shield, Heat
35	Screw (2)
