KEDS100WWH0 03 – DOOR

KEDS100WWH0 03 – DOOR

Written by

in

KEDS100WWH0 03 – DOOR

Products

Position	Product
1	Liner, Door
2	Frame, Inner
3	Screw
3	Seal, Flange (2)
4	Glass, Reflective
5	Seal, Door
6	Retainer,
7	WP3169203 Whirlpool Door Glass
8	Retainer, Glass (2)
9	Bumper (4)
10	Glass, Panel (White Model)
10	Glass, Panel (Black Model)
10	Glass, Panel (White)
11	Foil, Door
12	Handle, Door (White)
12	Handle, Oven Door
12	Handle, Door (Almond)
12	WP355515 Whirlpool Screw
13	Insulation, Door
14	Cap, Top
15	Clip, Mtg (2)
16	Screw,
16	Sheild, Door
18	Frame, Door
19	Back Splash (Screw (4) 10AB x 1/2“)
19	Top, Door (White Model)
19	Top, Door (Black Model)
