KEDS100WWH0 04 – CONTROL PANEL

Written by

Products

Position	Product
1	End Cap (Black, LH)
1	End Cap (Black, RH)
1	End Cap (White, LH)
1	End Cap (White, RH)
1	End Cap (Washer)
1	End Cap, L.H. (Almond)
1	End Cap (Almond, RH)
2	Glass, Control Panel (Almond)
2	Glass, Control Panel (Black)
2	Glass, Control Panel (White)
3	Rail, Top (Black)
3	Rail, Top (Bright Aluminum)
4	Trim, Center (Black)
4	Trim, Center (Bright Aluminum)
5	Trim, Vent Door (Brite Aluminum, R.H.)
5	Trim, Vent Door (Brite Aluminum, L.H.)
5	End Trim, Vent (Left Side)
5	End Trim, Vent (Right Side)
6	Door, Vent (Semi-Bright Aluminum)
6	Door, Vent
7	Screw, 10-32 x 1/2
7	Trim, Bottom
9	Retainer, Glass (4)
10	Bracket, Control Panel (2)
12	Bracket, Control
13	Electronic Range Control
13	Screw
14	Cover, Side (Right Hand)
14	Cover, Side (Left Hand)
17	Thermostat, Oven
17	WP313808 Whirlpool Screw
20	Lockwasher
20	Switch, Oven Light
20	White Model
21	Bezel, Switch (Almond)
21	Bezel, Switch (White)
21	Bezel Switch (1)
22	WP308605 Whirlpool Refrigerator Clamp
26	Knob, Bit Generator (Black)
26	Kno
26	Knob, Bit Generator (White)
31	Bracket, Control
31	WP355515 Whirlpool Screw
32	WPL 3149780
32	WPL 3149782
32	WPL 3149781
33	Trim, End Cap (Black)
33	Trim, End Cap (White)
33	Trim, End Cap (Almond)
34	Shield, Air
35	Screw (2)
35	Shield, Heat
35	WPL 309080
36	Shield, Control
