KEDT105VAL0 06 – DOOR

Products

Position	Product
1	Liner, Door
2	Frame, Inner
3	Seal, Flange (2)
4	Glass, Reflective
5	Seal, Door
6	Screw
6	Retainer,
7	WP3169203 Whirlpool Door Glass
8	Retainer, Glass (2)
9	Bumper (4)
10	Glass, Panel (Almond)
10	Glass, Panel (White)
10	Glass, Panel (Black Model)
11	Foil, Door
12	Handle, Oven Door (Almond)
12	Handle, Oven Door (White)
12	WP355515 Whirlpool Screw
12	Handle, Oven Door
13	Insulation, Door
14	Cap, Top
15	Clip (2)
16	Sheild, Door
16	Screw,
18	Frame (White)
18	Frame (Almond)
18	Frame, Door
19	Back Splash (Screw (4) 10AB x 1/2“)
19	Top, Door Frame
19	Door Top (Panoramic Grey)
19	WP308685 Whirlpool Microwave Screw
