KEDT105VWH3 04 – CONTROL PANEL

Products

Position	Product
1	End Cap. L.H. (Black)
1	End Cap, L.H. (Almond)
1	End Cap, L.H. (Almond)
1	End Cap. L.H. (White)
1	End Cap, L.H. (White)
1	End Cap. L.H. (Black)
1	End Cap (Washer)
2	Glass, Control Panel (White)
2	Glass, Control Panel (Black)
2	Glass, Control Panel (Almond)
3	Rail, Top (Bright Aluminum)
3	Rail, Top (Black)
4	Trim, Center (Black)
4	Trim, Center (Bright Aluminum)
5	Trim, Vent Door (Brite Aluminum, L.H.)
5	End Trim, Vent (Right Side)
5	End Trim, Vent (Left Side)
5	Trim, Vent Door (Brite Aluminum, R.H.)
6	Door, Vent (Semi-Bright Aluminum)
6	Door, Vent
7	Trim, Bottom
7	Screw, 10-32 x 1/2
9	Retainer, Glass (4)
10	Bracket, Control Panel (2)
12	Bracket, Control
13	Oven Control
13	Screw
17	Thermostat, Oven
17	WP313808 Whirlpool Screw
20	Lockwasher
20	White Model
20	Switch, Oven Light
21	Bezel, Switch (White – Almond)
21	Bezel, Switch (Almond)
21	Bezel Switch (1)
22	WP308605 Whirlpool Refrigerator Clamp
26	Kno
26	Knob, Bit Generator (Black)
26	Knob, Bit Generator (White)
31	Bracket, Control
32	WPL 3149780
32	WPL 3149782
32	WPL 3149781
33	Trim, End Cap (Black)
33	Trim, End Cap (Almond)
33	Trim, End Cap (White)
34	Shield, Air
35	Screw (2)
35	WPL 309080
35	Shield, Heat
36	Rail, Top (Seal, Backguard)
37	Shield, Control
