KEDT105WAL0 04 – CONTROL PANEL

Products

Position	Product
1	End Cap (Black, LH)
1	End Cap (Black, RH)
1	End Cap (White, LH)
1	End Cap (White, RH)
1	End Cap (Washer)
1	End Cap, L.H. (Almond)
1	End Cap (Almond, RH)
2	Glass, Control Panel (Almond)
2	Glass, Control Panel (Black)
2	Glass, Control Panel (White)
3	Rail, Top (Black)
3	Rail, Top (Bright Aluminum)
4	Trim, Center (Bright Aluminum)
4	Trim, Center (Black)
5	End Trim, Vent (Left Side)
5	Trim, Vent Door (Brite Aluminum, R.H.)
5	End Trim, Vent (Right Side)
5	Trim, Vent Door (Brite Aluminum, L.H.)
6	Door, Vent (Semi-Bright Aluminum)
6	Door, Vent
7	Trim, Bottom
7	Screw, 10-32 x 1/2
9	Retainer, Glass (4)
10	Bracket, Control Panel (2)
12	Bracket, Control
13	Screw
13	Oven Control
17	Thermostat, Oven
17	WP313808 Whirlpool Screw
17	WP965173 Whirlpool Dishwasher Screw
20	Lockwasher
20	Switch, Oven Light
20	White Model
21	Bezel, Switch (Almond)
21	Bezel Switch (1)
21	Bezel, Switch (White – Almond)
22	WP308605 Whirlpool Refrigerator Clamp
26	Knob, Bit Generator (Black)
26	Knob, Bit Generator (White)
26	Kno
31	Bracket, Control
32	WPL 3149780
32	WPL 3149781
32	WPL 3149782
33	Trim, End Cap (Black)
33	Trim, End Cap (Almond)
33	Trim, End Cap (White)
34	Shield, Air
35	WPL 309080
35	Screw (2)
35	Shield, Heat
36	Rail, Top (Seal, Backguard)
37	Shield, Control
