KEMC378KBL0 04 – LATCH

Written by

Products

Position	Product
1	4451759 Whirlpool Oven Exhaust Vent
2	4455178 Whirlpool Oven Top Elbow
3	4455177 Whirlpool Oven Bottom Elbow
5	W10491987 Whirlpool Foam Seal
9	WP4449809 Whirlpool Screw
9	Baffle, Rear
10	Latch Assy.
11	Solenoid
12	Microswitch N.C.
13	Microswitch
14	Spring, Latch
16	WPW10016550 Whirlpool Blower Cooling Fan
16	4455191 Whirlpool Oven Mounting Plate
