KEMS375SBL1 11 – CABINET
Written by
in
KEMS375SBL1 11 – CABINET
Products
Position
Product
1
Main Bottom
2
Insulation, Bottom
3
Door Gasket
4
Front Frame
5
Bottom Trim
7
Cover, Seal End
8
Oven Liner (See Pages 16 & 17)
9
Insulation, Top and Sides
10
Control Frame Support
11
Module Air Baffle
12
Compartment Top
13
Knob, Latch Lever
14
Latch Assembly (See Pages 14 & 15 For Further Breakdown)
15
Collector Box
16
Compartment Vent Duct<
17
Module Support Plate
18
Module Brace
19
Microwave Module
20
Module Trim
21
Control Frame Support
22
Exhaust Shield
23
Vent Box
24
Service Power Cord
25
Strain Relief Bushing
26
Cabinet Back Duct
27
Cabinet Side Upper
28
Vent Tube
29
Vent Tube, Retainer
30
Cabinet Side Extension
31
Trim Bracket
32
Intake Box Back
33
Module Intake Duct
34
Air Duct (Upper Oven) (Left)
35
Insulation, Rear
36
Rear Anchor
37
Cabinet Side, Lower
38
Cam Plate (Left Left)
38
Cam Plate (Right)
39
Hinge Assembly
40
Door Spring (Self Cleaning Oven)
41
Spring, Anchor
42
Cabinet Back
43
Cabinet Support (Left)
43
Cabinet Support (Right)
44
Rotisserie Motor
45
Rotisserie Motor Mounting Plate
46
RT Thermostat
47
RANGE ONLY 40W 120V APPL BULB
48
Socket, Lamp
49
Light Shield
50
Air Scoop
50
Probe Cover
50
Spacer
←
