KEMS376TWH1 02 – CONTROL PANEL , LIT/OPTIONAL

Written by

Products

Position	Product
3	Thermostat Disc
4	WPL 4175379
4	selector disc (2)
5	Screw (2)
5	nut (3)
5	Nut, Timer (4)
5	Clock
6	Control Mounting Panel
7	Indicator Light,
9	Switch, Selector
10	Thermostat
10	WP486579 Whirlpool Air Conditioner Screw
13	Meat Probe Indicator (Model KEBS145SBL1)
13	Screw, (2)
15	Screw,
15	Oven Light Switch
19	Indicator Light (2)
