KEMS378XAL0 05 – OVEN DOOR

Products

Position	Product
1	Screw, Black (2)
1	Liner, Door
2	Seal, Window
3	Spacer, Window
4	Latch, Strike
5	Insulation, Retainer
6	WP90767 Whirlpool Screw
6	Bracket, Glass Mtg.
7	Glass, Door (Black)
7	Glass, Door (Almond)
7	Glass, Door (White)
8	Glass, Reflective
9	Frame, Door
10	Handle, Door (Almond)
10	Screw
10	Handle, Door (White)
10	Handle, Door (Black)
11	Spacer (2) (Almond)
11	Spacer (2)
11	Spacer (2) (White)
13	Window Package
14	Insulation, Door
14	Vent, Lower Trim (Screw (2))
15	Bushing, Door Handle
16	Bumper, Door Glass
