KERC507HAL0 01 – COOKTOP, LITERATURE

Products

Position	Product
1	Safer Cooking Tips
1	WPL LIT9752776
1	WPL LIT9752387
1	Literature Parts (Cookbook (T/C Oven))
1	Literature Parts (Use & Care Guide)
1	Literature Parts (Smart & Easy Guide)
1	Literature Parts (Tech Sheet)
2	WP9780939 Whirlpool Cooktop Gasket
3	Rear Gasket
4	Frame, Cooktop (Almond)
4	Frame, Cooktop (Black)
4	Frame, Cooktop (Biscuit)
4	Frame, Cooktop (White)
5	Support, Element
6	Back Splash (Almond)
6	Back Splash (Black)
6	Back Splash (White)
6	Back Splash (Biscuit)
7	Brace, Support
8	Support Clips (4)
9	238614 Whirlpool Bumper Hinge
10	Hot Light
11	W10823692 Whirlpool Dual Radiant Element
11	W10823699 Whirlpool Right Front Surface Element
11	W10823698 Whirlpool Surface Element Right Rear
11	Element, Surface (Warm Zone)
14	Cooktop, Ceran (Black)
14	Cooktop, Ceran (Almond)
14	Cooktop, Ceran (White)
15	Rod, Small Ceran Element
16	Limiter, Temp. (LF)
16	Limiter, Temp. (LR-RF-RR)
16	Limiter, Temp (Warm Zone)
17	WP9781235 Whirlpool Clip
18	Cover, Vent (Almond)
18	Cover, Vent (White)
18	Cover, Vent (Biscuit)
18	Cover, Vent (Black)
19	Rod, Large Ceran Element
20	Clip, Vent Cover
25	Vent Gasket
26	Screw, (4) 10PH-B x 3/4
27	Back Splash (Screw (4) 10AB x 1/2``)
28	Spring, Warm Zone Element
28	Screw (4) 10 x 1/2
