| 1 | Main Bottom |
| 2 | Insulation, Bottom |
| 3 | Door Gasket KESO-170/175, KEDO-270/275 |
| 4 | Front Frame, Lower Oven (KEDO-276) |
| 5 | Bottom Trim |
| 6 | Cover - Seal End |
| 7 | Oven Liner (Lower Oven) (See Page 10) |
| 8 | Insulation, Top & Sides |
| 10 | Knob, Latch Lever |
| 11 | Latch Assembly (See Page 6 For Further Breakdown) |
| 12 | Insulation, Rear |
| 13 | Rear Anchor |
| 14 | Cabinet Side - Lower Ov |
| 15 | WPL CC20050 |
| 16 | WPL CC32307 |
| 17 | WPL CC71633 |
| 18 | WPL CC32424 |
| 19 | Front Frame - Upper Oven (KEDO-276) |
| 20 | Oven Liners, Single or Upper Oven (See Page 10) |
| 21 | WPL CC31734 |
| 22 | Compartment Top - Upper Oven (KEDO-276) |
| 23 | Vent Box |
| 24 | WPL CC70863 |
| 25 | WPL 3052484 |
| 26 | WPL CC22045 |
| 27 | WPL CC32220 |
| 28 | Latch Assembly (See Page 6) |
| 29 | WPL 3053511 |
| 30 | WPL CC32284 |
| 31 | Cabinet Back (KESO-176) |
| 32 | WPL CC22143 |
| 33 | WPL BL27 |
| 34 | WPL CC566083 |
| 35 | WPL CC22022 |
| 36 | WPL 305104 |
| 37 | WPL CC19760 |
| 38 | WPL CC71196 |
| 39 | WPL CC31876 |
| 40 | WPL 3050281 |
| 41 | WPL 3050291 |
| 42 | WPL 3050282 |
| 43 | WPL 3050292 |
| 44 | WPL CC71194 |
| 45 | WPL CC22058 |
| 46 | WPL CC606517 |
| 47 | WPL CC22049 |
| 48 | WPL CC22054 |
