KF404GDD6 02 – BODY PARTS

Products

PositionProduct
*72547WCI 3934058
1OVEN ASSEMBLY-RIGHT
2WCI 3051511
3316116400 Frigidaire Oven Light Socket
4316538904 Frigidaire Oven Lamp Light
55304524341 Frigidaire Lens
6RETAINER-LENS
6AINSULATION – OVEN WRAP
7TUBE – OVEN VENT
7AINSULATION
8ASIDE PANEL LH-ALMD
8SIDE PANEL RH-ALMD
9PARTITION – CENTER
10BOTTOM COMPLETE
11WCI 3204827
12WCI 3206275
13AWCI 3204823
13WCI 3204822
14WCI 5301307085
15Channel,oven support ,front
16SCREW-LEVELING (4)
19WCI 5301314211
20WCI 5303294354
21WCI 5303294355
22WCI 5303209319
23ARAIL, DRAWER LH
23WCI 5308015746
24GUIDE-DRAWER FRNT (2)
25GUSSET – BKGRD (2)
26BRACKET-THERMO BULB (2)
275304409888 Frigidaire Oven Terminal Block with Hardware
28PLATE=GROUND STRAP
29RAIL – COMPL RACK (2)
30316067902 Frigidaire Oven Rack
31BROILER PAN
32BROILER GRILL
33WIRE, COVER
34BUMPER, COOKTOP (4)
35RACK – COMPLETE
37WCI 3204318
