KF450GDH8 06 – BODY PARTS

KF450GDH8 06 – BODY PARTS

Written by

in

KF450GDH8 06 – BODY PARTS

Products

PositionProduct
*44245WCI 191S021P46
*44244ANTI-TIP KIT, (NON-ILLUSTRATED)
*44244CLIP CAPILLARY
1APANEL-SIDE LH WHEAT
1ASIDE PANEL LH-ALMD
1SIDE PANEL RH-ALMD
1ASIDE PANEL, LH WHITE
3BUMPER, COOKTOP (4)
3ARETAINER, INSULATION (2)
5SCREW-LEVELING (4)
6ARAIL, DRAWER LH
6WCI 5308015746
7GUIDE-DRAWER FRNT (2)
8BUTTON-PLUG
9BODY-OVEN
10WCI 3051511
11316116400 Frigidaire Oven Light Socket
12316538904 Frigidaire Oven Lamp Light
13RETAINER-LENS
145304524341 Frigidaire Lens
15SPACER, DRAWER RAIL (2)
16WCI 3205234
17WCI 3205539
18316067902 Frigidaire Oven Rack
18ARACK-OFFSET
195304409888 Frigidaire Oven Terminal Block with Hardware
20PLATE=GROUND STRAP
21WCI 5303207390
22WCI 3206275
27WCI 3201632
28WCI 3051634
29INSULATION
30AWCI 3017482
30WCI 3017481
31WIRE, COVER
32PANEL-BACK
33WCI 08012542
34SWITCH, DOOR
35WCI 08007445
36WCI 08007444
37WCI 5033207391
38WCI 3016281
39WCI 3201631
40SWITCH, LOWER
41TUBE-OVEN VENT
42LATCH, MOTOR
46WCI 3202387
47HOUSING-DOOR LATCH
48AXLE – HINGE (2)
49WCI 3051649
50WCI 3202114
53WCI 3019063
54WCI 08003090
55WCI 3206095
56WCI 3202082
