KF480ND1 05 – DOOR PARTS

KF480ND1 05 – DOOR PARTS

Written by

in

KF480ND1 05 – DOOR PARTS

Products

PositionProduct
1GLASS, OUTER, BLACK
2WCI 3206077
3WCI 5301167830
4WCI 3017634
5WCI 3206078
6WCI 3008673
7GLASS PACKAGE
8WCI 5303207187
9WCI 3051706
10BUTTON PLUG
1108002868 Frigidaire 0 Screw Assembly
12WCI 08002847
13DOOR LINER
14HINGE, ASSY (2)
15WCI 5308003186
16WCI 5303051860
17WCI 5303051713
18RETAINER, GLASS (2)
19INSULATION, AIRWASH
20WCI 3051712
21WCI 3008677
22FOIL – ALUMINUM J
