KF590HDW7 06 – BODY PARTS

Products

Position	Product
*71516	WCI 19100210049
1	SIDE PANEL, LH WHITE
1	SIDE PANEL, RH WHITE
2	FRONT – OVEN
3	BUMPER, COOKTOP (4)
4	RETAINER, INSULATION (2)
5	SCREW-LEVELING (4)
6	WCI 5308015746
6A	RAIL, DRAWER LH
7	GUIDE-DRAWER FRNT (2)
8	WCI 3205257
9	WCI 5303293103
10	WCI 5303271606
11	316116400 Frigidaire Oven Light Socket
12	316538904 Frigidaire Oven Lamp Light
13	RETAINER-LENS
14	5304524341 Frigidaire Lens
15	SPACER, DRAWER RAIL (2)
16	WCI 3205234
17	WCI 5303292688
18A	RACK-OVEN OFFSET
18	316067902 Frigidaire Oven Rack
19	5304409888 Frigidaire Oven Terminal Block with Hardware
20	PLATE=GROUND STRAP
21	WCI 5303207391
22	WCI 3206275
23	WCI 3202082
24	INSULATION, OVEN WRAP
25	PLUG BUTTON (NON-ILLUSTRATED)
26	WCI 3201632
27	WCI 3016281
28	WCI 3051634
29	INSULATION
30A	WCI 3017482
30	WCI 3017481
31	WIRE, COVER
32	PANEL-BACK
33	WCI 5303292687
34	WCI 3017799
35	WCI 08007445
36	WCI 08007444
37	TUBE-OVEN VENT
38	LATCH, MOTOR
39	LATCH-DOOR
40	HOUSING-DOOR LATCH
41	AXLE – HINGE (2)
42	WCI 3051649
46	WCI 5303207389
47	WCI 3019063
47B	5303284616 Frigidaire Range Bulb Clip Thermostat
47A	ANTI-TIP KIT, (NON-ILLUSTRATED)
48	WCI 3201631
49	BALLAST-LAMP (NON-ILLUSTRATED)
50	WCI 3051655
51	BRACKET, VENT TUBE
52	GASKET, OVEN VENT TUBE
53	WCI 5303293025
