KGCG260SAL1 02 – COOKTOP AND MAIN BODY, LITERATURE

Products

PositionProduct
Repair Parts List
Instructions, Installation
Guide, Use & Care
1WPW10068250 Whirlpool Dishwasher Screw
2Pan, Heat Shield
4Channel, Grill Harness
5Bushing, Electrical (Harness Channel)
6Screw, Self Tapping (8-18 X 3/8) Phil. Bind. Hd. Type AB
7Element, Grill (1700 W 120 V)
8Cooktop (White)
8Cooktop (Onyx Black)
8Cooktop (Almond)
8Cooktop (Brushed Chrome)
9Bowl, Drip (2) (Power Burner)
10Bowl, Drip (2) (Daisy Burner)
11Grate, Cooktop (4)
12Receptacle, Grill Element
13Clip, Grill Ground
14Mounting Hardware
14Screw
