KGCG260SAL2 02 – COOKTOP, LITERATUREadmin2025-04-26T11:42:54+00:00KGCG260SAL2 02 – COOKTOP, LITERATURE
Products
| Position | Product |
|---|
| NI | Screw |
| NI | Mounting Hardware |
| NI | Screw, Self Tapping (8-18 X 3/8) Phil. Bind. Hd. Type AB |
| Guide, Use & Care |
| Instructions, Installation |
| Repair Parts List |
| 2 | Pan, Heat Shield |
| 4 | Channel, Grill Harness |
| 5 | Bushing, Electrical (Harness Channel) |
| 7 | Element, Grill (1700 W 120 V) |
| 8 | Cooktop (Brushed Chrome) |
| 8 | Cooktop (Almond) |
| 8 | Cooktop (Onyx Black) |
| 8 | Cooktop (White) |
| 9 | Bowl, Drip (2) (Power Burner) |
| 10 | Bowl, Drip (2) (Daisy Burner) |
| 11 | Grate, Cooktop (4) |
| 12 | Receptacle, Grill Element |
| 13 | Clip, Grill Ground |
