KGCG260SAL2 03 – CONTROL PANEL

Products

Position	Product
NI	Nut (4) No.8-32
NI	Screw (4), No.8-32x.500
NI	Screw, (2)
1	Switch, Infinite
2	Light, Grill Indicator
3	Frame, Glass Mounting
8	Panel, Control (Glass) (Kitchen Aid Name- plate)
9	Washer (4)
10	WP3188425 Whirlpool Seal Switch
11	Nut, Hex Jam (4)
12	Grommet, Control Panel Positioning (4)
13	Locknut, Control Panel Positioning (4)
14	Cover, Infinite Switch
16	Knob, Control (4)
17	Knob, Control (4)
