KGCG260SAL2 04 – BURNER BOX

Products

Position	Product
NI	Wire, Spark Module To Terminal Block
NI	Wire, Direct Spark (17``)
NI	Wire, Direct Spark (47``)
NI	Base Cover Screws
NI	Screw
NI	Screw, No.10-24 X 3/8`` Hex TCS
NI	WP313808 Whirlpool Screw
NI	Screw, (2)
NI	Screw
1	Box, Burner
2	Power Cord
3	Bushing, Strain Relief
4	Block, Terminal
6	Manifold Ass`y
8	Valve, Daisy (2) (Bolt Thru)
9	Valve, Power (2) (Bolt Thru)
10	Switch, Gas Ignitor (4)
11	WP3188425 Whirlpool Seal Switch
13	Bracket, Spark Module
15	Module, Spark Ignition
18	Bracket, Burner Base (Left)
18	Bracket, Burner Base (Right)
20	Cover, Spark Module
22	Pan, Heat Shield Burner Box
24	Venturi (Left Front) (Includes Illus. 25 & 26)
25	Mixer Valve
27	Gasket, Venturi
29	4175453 Whirlpool Oven Surface Igniter
31	Venturi (Right Front) (Includes Illus. 25 & 26)
32	Venturi (Right Rear)
33	Venturi (Left Rear)
34	Hinge, Cooktop (2)
36	Rod, Cook Support
37	Tip, Rod Support
38	Bracket, Support Rod
40	REGULATOR, PRESSURE
41	Daisy Burner (L.F. & R.R.)
42	Burner, Power (R.F. & L.R.)
