KGCG260SBC0 02 – COOKTOP AND MAIN BODY, LITERATURE

KGCG260SBC0 02 – COOKTOP AND MAIN BODY, LITERATURE

Written by

in

KGCG260SBC0 02 – COOKTOP AND MAIN BODY, LITERATURE

Products

PositionProduct
Instructions, Installation
Guide, Use & Care
Repair Parts List
1WPW10068250 Whirlpool Dishwasher Screw
2Pan, Heat Shield
4Channel, Grill Harness
5Bushing, Electrical (Harness Channel)
6Screw, Self Tapping (8-18 X 3/8) Phil. Bind. Hd. Type AB
7Element, Grill (1700 W 120 V)
8Cooktop (White)
8Cooktop (Almond)
8Cooktop (Brushed Chrome)
8Cooktop (Onyx Black)
9Bowl, Drip (2) (Power Burner)
10Bowl, Drip (2) (Daisy Burner)
11Grate, Cooktop (4)
12Receptacle, Grill Element
13Clip, Grill Ground
14Mounting Hardware
14Screw
