KGCU482VSS00 02 – BURNER BOX, GAS VALVES, AND SWITCHES

Products

Position	Product
NI	W10158807 Whirlpool Burner Tube
NI	W10280797 Whirlpool Gas Tubing
NI	W10115910 Whirlpool Gas Tubing
NI	W10115911 Whirlpool Gas Tubing
NI	TUBING, GAS (LEFT REAR)
1	W10250473 Whirlpool Drip Tray
2	SCREW
3	WP9759091 Whirlpool Regulator
4	W10189107 Whirlpool Mounting Bracket
5	DEFLECTOR, GRILL
6	W10223569 Whirlpool Burner Grille
7	MANIFOLD
8	WPW10371235 Whirlpool Burner Valve
9	W10189097 Whirlpool Bushing Assembly
10	W10189140 Whirlpool Screw
12	BURNER BOX
13	BRACKET, GRILL ORIFICE MOUNTING
14	WPW10326645 Whirlpool Burner Valve
16	HOLDER, DRIP TRAY
17	W10250468 Whirlpool Grille Guard
18	BRACKET, BURNER (LEFT FRONT, LEFT REAR & RIGHT FRONT)
19	4450800 Whirlpool Oven Screw
20	WPW10385583 Whirlpool Burner Valve
21	W10115843 Whirlpool Access Cover
23	W10189177 Whirlpool Seal Switch
25	COVER, BURNER BOX
26	Bracket, Mounting Orifice
27	W11601369 Whirlpool Spark Module
28	DRIP TRAY, ROUTER 1
29	W10305285 Whirlpool Grill Valve
30	FLAME SPREADER
32	WPW10267890 Whirlpool Module
33	BRACKET, GRILL IGNITOR
34	W10268770 Whirlpool Surface Igniter
