KHWS160JBU2 01 – OUTER COVER & INSULATION PARTS

KHWS160JBU2 01 – OUTER COVER & INSULATION PARTS

Written by

in

KHWS160JBU2 01 – OUTER COVER & INSULATION PARTS

Products

PositionProduct
1Bushing, Molded
2Cap, Bottom
3W11245710 Whirlpool Refrigerator Screw
54159493 Whirlpool Lockwasher
6Strain Releif, Power Cord
7Shell
9Displacer
10Insulation, Top
11Insulation, Bottom
12Clamp, Hose
13Hose, Clear
15Screw, 8-32X.5 (stainless)
16Cord, Power
17Front Cover
18WP313808 Whirlpool Screw
19Grommet
20O-Ring
20Literature Parts (Repair Parts List)
20FOLLOWING PARTS NOT ILLUSTRATED
20LITERATURE PARTS
20Instructions, Installation & Use And Care
