KS220GDW3 04 – COOKTOP AND BROILER PARTS

KS220GDW3 04 – COOKTOP AND BROILER PARTS

Written by

in

KS220GDW3 04 – COOKTOP AND BROILER PARTS

Products

PositionProduct
1WCI 08015918
2A316048413 Frigidaire Oven Range Chrome 8" Drip Bow
2316048414 Frigidaire Oven Range Chrome 6" Drip Bowl
3A316442300 Frigidaire Oven 2100W Coil Element 8
3318372210 Frigidaire Oven Range 6" 1250W Surface Element
45303935058 Frigidaire Oven Burner Receptacle Kit
5HINGE ARM (2)
65303051516 Frigidaire Broil Element
75303051519 Frigidaire Oven 2600W Bake Element
8HANGER – BROIL UNIT
9ROD-TOP SUPPORT
