KSRG25FVMS04 07 – FREEZER DOOR PARTS

KSRG25FVMS04 07 – FREEZER DOOR PARTS

Written by

in

KSRG25FVMS04 07 – FREEZER DOOR PARTS

Products

PositionProduct
1FREEZER DOOR (INCLUDES No.8 AND DISPENSER FRONT PARTS) (MONO STAINLESS)
2Handle, Door (Stainless Steel)
4WPW10170540 Whirlpool Screw
5WP3400012 Whirlpool Refrigerator Screw
6SCREW
7WP2171157 Whirlpool Shelf Trim
8W10136735 Whirlpool Refrigerator Door Gasket
92323581 Whirlpool Refrigerator Tube Cover
10WPW10307490 Whirlpool Door Trim Assembly
13WPW10193328 Whirlpool Refrigerator Wire Harness
14Door Closer, Upper Cam
16WPW10142233 Whirlpool Refrigerator Screw
17BRACKET, DOOR STOP (CHROME)
18WP2182181 Whirlpool Refrigerator Thimble
