KSRP22FTWH02 12 – CONTROL PARTS, OPTIONAL PARTS (NOT INCLUDED)

KSRP22FTWH02 12 – CONTROL PARTS, OPTIONAL PARTS (NOT INCLUDED)

Written by

in

KSRP22FTWH02 12 – CONTROL PARTS, OPTIONAL PARTS (NOT INCLUDED)

Products

PositionProduct
350930 Whirlpool White Spray Paint
CEMENT, ALUMILASTIC (1 1/4 OZ.)
Enamel, Black (1 Qt. Uncut)
WPL 799833
8171357 Whirlpool Spray Nozzle
PAINT, TOUCH-UP (1/2OZ. GRAPHITE)
PAINT, BULK (1 QT. GRAPHITE)
285006 Whirlpool Spray
72032 Whirlpool Touch Up Paint Black
WPL 8201806
Important: The spray paint is not to be us
WPL ARI100051A
WPL ARI100052A
WPL ARI100053A
TAPE, VINYL (3/4 X 108“)
4392899 Whirlpool Biscuit Touch-Up Paint
212643 Whirlpool Refrigerator Permagum Sealer
799344 Whirlpool Refrigerator Paint
350942 Whirlpool Spray Paint
4392901 Whirlpool Biscuit Spray Paint
833938 Whirlpool Refrigerator Terminal
WP503695 Whirlpool Refrigerator Sealer
WP505587 Whirlpool Refrigerator Sealer
72017 Whirlpool Appliance Touch-Up Paint White
WP542638 Whirlpool Refrigerator Grease
Torx Key
PAINT, BULK (1 QT.) (BISCUIT (UNCUT))
1Control Box
2Cover, Ctrl Box
3WP3196557 Whirlpool Screw
4WP2149705 Whirlpool Refrigerator Door Switch
5Electronic Control
6WP67006908 Whirlpool Refrigerator Screw
7Insert, Control Board (Not Serviceable, Order 5)
8940014 Whirlpool Refrigerator Primary Button Plug
94387478 Whirlpool Refrigerator Light Socket
10RANGE ONLY 40W 120V APPL BULB
11Control Box Harness
12Overlay, Control Box
13WP1115374 Whirlpool Refrigerator Clip
