KSRS27QAAL04 07 – REFRIGERATOR DOOR

KSRS27QAAL04 07 – REFRIGERATOR DOOR

Written by

in

KSRS27QAAL04 07 – REFRIGERATOR DOOR

Products

PositionProduct
1Refrigerator Door (Includes Item 8) (White)
1Refrigerator Door (Includes Item 8) (Almond)
3Door, Compartment
5WPL 1125981
6Butter, Tray
7Insert, Handle (Almond)
7Insert, Handle
82159075 Whirlpool Door Gasket Seal
10End Cap (2)
11Screw Anchor (2)
12Screw
14Handle
16Spacer, Handle
19WP1104787 Whirlpool Refrigerator Shim
204318165 Whirlpool Refrigerator Door Closure Cam Kit
22WP489069 Whirlpool Compactor Screw
23Bracket, Door Stop (Black)
27Retainer, Insert
28Retainer, Insert
31Trim, Door
35Shelf Bin (4)
36WP488729 Whirlpool Refrigerator Door Screw
36Black Glass
36Handle Inserts (Black Grille Kit)
36Handle Inserts (Woodgrain)
36Handle Inserts (Black)
36Acrylic Panel Kit (White)
36Acrylic Panel Kit (Almond)
36Trim Kit Trim Kit Panels
