KSRS27QAAL04 10 – UNIT

Products

PositionProduct
1WP486692 Whirlpool Refrigerator Nut
2Fan, Blade
3Condenser Assembly
5Clip, Wire
6681390 Whirlpool Refrigerator Screw
7Clip, Tube (3)
9WP2158826 Whirlpool Refrigerator Dampener
11case spring
12Case, Relay
13Overload (Includes Relay)
17WPW10662129 Whirlpool Refrigerator Run Capacitor
18SLEEVE
19Screw Grommet
20Clip (2)
21WP489478 Whirlpool Refrigerator Screw
22Evaporator
23Clamp
24833697 Whirlpool Condenser Fan Motor
25Tray, Evaporator
26Heat Shield
27W10843121 Whirlpool Refrigerator Tube
28Compressor (Includes Items 43, 44, 45, 46, 47, 56, 57 & 59) (Also Order 876765 Tube Kit)
302304904 Whirlpool Frame Assembly
32Fan, Motor Bracket
33Heater, Defrost
34Clip
35WPW10225581 Whirlpool Refrigerator Defrost Thermostat
37Screw
38WP2172890 Whirlpool Refrigerator Wire
39Grommet (Production)
40489340 Whirlpool Refrigerator Screw
41W10896764 Whirlpool Refrigerator Air Baffle
42Clip, Heat Shield
43Relay (Order Overload, No.44, To Obtain Relay)
44Overload
45Cover
46Strap
482305374 Whirlpool Refrigerator Unit Rail
49Screw, 8 x 3/8
50Guard, Fan
53WP489427 Whirlpool Refrigerator Screw
55WPW10141625 Whirlpool Refrigerator Screw Assembly
56W11693756 Whirlpool Screw Assembly
59Spring-Tube
63VALVE, ACCESS (1/2“)
63VALVE, ACCESS (5/8“)
63978026 Whirlpool Refrigerator Primary Valve
63978027 Whirlpool Refrigerator Primary Valve
63WP4211117 Whirlpool Refrigerator Connector
63876764 Whirlpool Refrigerator Primary Valve
63978030 Whirlpool Refrigerator Valve
63WP978025 Whirlpool Refrigerator Valve
