KSRT22DTTO00 04 – REFRIGERATOR DOOR

KSRT22DTTO00 04 – REFRIGERATOR DOOR

Written by

in

KSRT22DTTO00 04 – REFRIGERATOR DOOR

Products

PositionProduct
1Refrigerator, Door Panel (White)
1Refrigerator, Door Panel (Almond)
1Refrigerator, Door Panel (Toast)
1Refrigerator, Door Panel (Platinum (Also Order Item 19 When Replaceing Door))
2Tap Plate
34318165 Whirlpool Refrigerator Door Closure Cam Kit
4Shim
5Bracket, Door Stop
6Trim, Door
7WP488921 Whirlpool Refrigerator Screw
7Screw (Repair)
8Cap, Hinge Sleeve (2)
9Retainer, Handle
10Retainer Side, Gasket
11Retainer, Top & Bottom
122188404A Whirlpool Refrigerator Door Gasket
13SCREW
13WP489069 Whirlpool Compactor Screw
14Handle, Door
15WP939101 Whirlpool Refrigerator Plate
17WP8281206 Whirlpool Refrigerator Screw
18Screw, 8-15 x 1 1/4 (8)
19WPL 876029
21Insert, Handle
22Trim, Push-In Top & Bottom (2)
23End Cap, Top
24End Cap, Bottom
25Trim, Push-In Side (2)
26Screw, 6-32 x 1/2
27Interior Door, Panel
33Shelf Ladder
34Expansion Clip
36Compartment Door
39Cantilever, Door Shelf
40Shelf, Door Cantilever Bin
43WP1104787 Whirlpool Refrigerator Shim
44Spacer, Shelf
