KSRT26DTPL00 07 – FREEZER DOOR

Products

Position	Product
1	Exterior Door Panel Freezer (Almond)
1	Exterior Door Panel Freezer (White)
1	Exterior Door Panel Freezer (Toast)
1	Exterior Door Panel Freezer (Platinum)
2	Plug, Crossover
3	Tap Plate
4	4318165 Whirlpool Refrigerator Door Closure Cam Kit
5	WP489069 Whirlpool Compactor Screw
6	Trim, Door
7	Tube, Door Wiring
8	Wire Connector
9	Bracket, Door Stop
10	Trim, Push-In (4)
11	Screw (Repair)
11	Screw, 89 x 5/8
12	Dispenser, Insulation
13	Retainer, Gasket Side
14	Retainer, Gasket Top & Bottom
15	Door Gasket, Magnetic (For Platinum Model Only)
16	SCREW
17	Handle, Door
18	Trim, Push-In Upper Sides (2)
19	Retainer, Handle (Top)
20	Retainer, Handle (Bottom)
22	WP8281206 Whirlpool Refrigerator Screw
23	Trim, Push-In Lower Sides (2)
24	Trim, Dispenser
25	Screw (Repair)
26	End Cap, Top
27	Insert, Handle
28	End Cap, Top
29	WP939101 Whirlpool Refrigerator Plate
30	Chute, Ice
31	Overlay, Ice Dispenser
32	Expansion Clip
33	WP488729 Whirlpool Refrigerator Door Screw
34	Interior, Door Panel
35	Door Shelf, Ladder (Top)
36	Door Shelf, Ladder (Bottom)
37	WP1104787 Whirlpool Refrigerator Shim
38	Spacer, Shelf
39	Screw, 8-15 x 1 1/4 (8)
40	Door Shelf, Cantilever
41	Screw, 6-32 x 1/2
