KSSC42QTS03 11 – FREEZER DOOR PARTS

Products

Position	Product
1	Freezer Door (Includes 13) (Universal Silver)
2	HINGE-DOOR
3	W11474472 Whirlpool Screw
4	W11724512 Whirlpool Door Hinge
5	W11673500 Whirlpool Door Hinge
6	WP2266905 Whirlpool Refrigerator Door Gasket
7	WP2316868 Whirlpool Refrigerator Handle
8	Spacer, Door (Handle Side)
9	SKIN, DOOR
10	WP8281250 Whirlpool Refrigerator Screw
11	2005433 Whirlpool Refrigerator Spacer
12	W10759522 Whirlpool Screw
13	2257385 Whirlpool Refrigerator Spacer
14	SPACER, DOOR-SKIN (HINGE SIDE)
15	WP308544 Whirlpool Screw
16	2328901 Whirlpool Filler Panel
16	2328902 Whirlpool Filler
17	BRACE, DOOR CORNER
18	W10323602 Whirlpool Refrigerator Cantilever Bin
19	W10127710 Whirlpool Refrigerator Plate
