KSSP48MFW05 08 – FREEZER SHELF

KSSP48MFW05 08 – FREEZER SHELF

Written by

in

KSSP48MFW05 08 – FREEZER SHELF

Products

PositionProduct
1Solid Shelf
2Front, Ice Compartment
3Shelf, Fixed (2)
3Shelf, Fixed (Large)
4Basket (2)
5Trim, Basket
6Basket Slide (Right Side)
6Basket Slide (Left Side)
7W11624204 Whirlpool Screw
82003046 Whirlpool Refrigerator Plug
92003047 Whirlpool Refrigerator Plug
10Front Cover
11Slide, Container (Right Side)
112006518 Whirlpool Refrigerator Track
12Ice Container
13Roller Stop
14Eyelet, Roller
15Roller
16WPW10272364 Whirlpool Refrigerator Screw
17WP488787 Whirlpool Refrigerator Screw
