| Repair Parts List |
| Instructions, Installation |
| 1 | Power Unit Complete Model KPID850T (Interior Mounted, Includes Illus 2,3,4) |
| 2 | Wall Cap, 6`` |
| 3 | Capacitor, Motor |
| 4 | Cap, Capacitor |
| 5 | Motor (Includes Capacitor & Cap) |
| 6 | Blade, Fan |
| 7 | Cover, Motor (Wall Mount) |
| 8 | Impeller |
| 9 | Plate, Adaptor (With Damper) |
| 10 | Housing, (Not Serviceable) |
| 11 | Housing, (Not Serviceable) |
| 12 | Power Unit Complete Model KPED-890T (Exterior Wall Mount) (Includes Key 5 Thu Key 11) |
| 13 | Roof Mounting Kit (Dome Cover And Flashing) |
| 13 | 9`` Elbow (Not Included, Purchase Locally) |
