KTRF18KTAL00 07 – LINER , LIT/OPTIONAL

KTRF18KTAL00 07 – LINER , LIT/OPTIONAL

Written by

in

KTRF18KTAL00 07 – LINER , LIT/OPTIONAL

Products

Position	Product
	WPL LIT879906
	Torx Key
	WPL LIT1107184
	WPL LIT1117587
	WPL LIT1117503
1	Liner (Not A Serviceable Part)
2	Stud, Shelf (2)
3	Grommet (2)
4	Grommet (4)
5	Shelf Stud, Saddle L.S.
6	Liner Wiring (Ice Maker)
7	Hole, Plug
8	Grommet
9	Hole, Plug
11	482469 Whirlpool Refrigerator Evaporator Fan Motor Kit
12	Hole Plug, Evaporator
13	Blade, Fan
14	Ring, Compression
16	WP488163 Whirlpool Refrigerator Screw
17	Stud, Support (2)
18	Retainer, Stud (4)
19	Grommet, Crisper Cover
20	Stud, Shelf (4)
21	Fastener, Wire
22	Terminal Block (Single)
23	Air Duct
24	Sealing Gasket
25	Cover, Evaporator
26	Shelf Stud Saddle (R.S.)
27	Screw Grommet
28	Wiring Shield
29	WP488729 Whirlpool Refrigerator Door Screw
30	Terminal Block (Multiple)
31	Grommet (3)
32	Bracket, Double
33	Grommet
34	Bracket, Single
35	Receptacle Cap
36	W11693756 Whirlpool Screw Assembly
38	Gasket, Sealing
40	Gasket, Evaporator
44	Shelf Stud
45	W11624204 Whirlpool Screw
46	Socket
47	W11679940 Whirlpool Refrigerator Light Bulb Assembly
49	Light Lens
50	Gasket, Top
51	Baffle, Liner Top
52	Platinum (Uncut)
52	WP505587 Whirlpool Refrigerator Sealer
52	WP542638 Whirlpool Refrigerator Grease
52	Almond (Uncut)
52	WP489069 Whirlpool Compactor Screw
52	72113 Whirlpool Touch-Up Paint
52	WP72107 Whirlpool Touchup
52	WP503695 Whirlpool Refrigerator Sealer
52	833938 Whirlpool Refrigerator Terminal
52	799344 Whirlpool Refrigerator Paint
52	72017 Whirlpool Appliance Touch-Up Paint White
52	350956 Whirlpool Spray Assembly
52	350930 Whirlpool White Spray Paint
52	876370 Whirlpool Refrigerator Insulation
52	TAPE, VINYL (3/4 X 108“)
52	Toast
52	WPL 72112
52	Silicone (Spray)
52	WPL 799832
52	212643 Whirlpool Refrigerator Permagum Sealer
52	350942 Whirlpool Spray Paint
52	511873 Whirlpool Refrigerator Paint
52	606755 Whirlpool Refrigerator Bag
52	72032 Whirlpool Touch Up Paint Black
52	285006 Whirlpool Spray
52	WPL 876029
52	WPL 799833
52	CEMENT, ALUMILASTIC (1 1/4 OZ.)
52	Enamal, Toast (1 Qt. Uncut)
52	Paint, Spray (13 Oz.) (Platinum)
52	Leveler (Thinner)
