KTRF18MTTO00 07 – LINER

Products

Position	Product
1	Liner (Not A Serviceable Part)
2	Stud, Shelf (2)
3	Grommet (2)
4	Grommet (4)
5	Shelf Stud, Saddle L.S.
6	Liner Wiring (Ice Maker)
7	Hole, Plug
8	Grommet
9	Air Deflector
11	482469 Whirlpool Refrigerator Evaporator Fan Motor Kit
12	Hole Plug
13	Blade, Fan
14	Ring, Compression
15	WP488163 Whirlpool Refrigerator Screw
17	Stud, Support (2)
18	Retainer, Stud (4)
19	Grommet, Crisper Cover
20	Stud, Shelf (4)
21	Fastener, Wire
22	Terminal Block (Single)
23	Air Duct
24	Sealing Gasket
25	Cover, Evaporator
26	Shelf Stud Saddle (R.S.)
27	Screw Grommet
28	Wiring Shield
29	WP488729 Whirlpool Refrigerator Door Screw
30	Terminal Block (Multiple)
31	Grommet (3)
32	Bracket, Double
33	Grommet
34	Bracket, Single
35	Screw Grommet
36	W11693756 Whirlpool Screw Assembly
37	Support Clip
38	Gasket, Sealing
39	SCREW
40	Gasket, Evaporator
42	Grommet
44	Shelf Stud
45	W11624204 Whirlpool Screw
46	Socket
47	W11679940 Whirlpool Refrigerator Light Bulb Assembly
49	Light Lens
50	Gasket, Top
51	Baffle, Liner Top
52	WP489069 Whirlpool Compactor Screw
