KTRF20KVPL00 07 – FREEZER DOOR

Products

PositionProduct
1Freezer Door (White)
1Freezer Door (Almond)
1Door, Freezer (Also Order Item 36) (Toast)
1Door, Freezer (Also Order Item 36) (Platinum)
2Cap, Hinge Sleeve (2)
3Hole Plug (Platinum)
3WP2212648 Whirlpool Refrigerator Hinge Sleeve Hole Plug
3Hole Plug (Almond)
3Hole Plug (Toast)
4Hole Plug (2) (Toast)
4Hole Plug (2) (Platinum)
4Hole Plug (2) (Almond)
4Hole Plug (2)
5W10833053 Whirlpool Refrigerator Plate
6Bracket, Door Stop
7WP488921 Whirlpool Refrigerator Screw
8Retainer Gasket Side
9Retainer, Gasket Top
102188460A Whirlpool Refrigerator Door Gasket
11WP489069 Whirlpool Compactor Screw
11SCREW
12Handle
13Insert, Handle
14Spacer, Handle
15WPL 876029
16Spacer, Handle
18Spacer
20WP488920 Whirlpool Refrigerator Screw
20Screw (Repair)
22Screw (Repair)
24WPL 1103184
25Trim, Door Shelf (2)
26WP849996 Whirlpool Refrigerator Endcap Trim
27Insert, Nameplate
