KTRF22MSTOY0 07 – LINER
Written by
in
KTRF22MSTOY0 07 – LINER
Products
Position
Product
1
Grommet
2
Grommet
3
Screw, Grommet
5
Shelf, Stud
6
Stud, Support (2)
7
Grommet, Crisper Cover
11
Stud, Shelf (3)
13
Screw Grommet
14
Shelf Stud
15
Retainer, Stud (4)
16
Hole, Plug
17
Screw, Anchor (3)
18
Screw Grommet
19
W11624204 Whirlpool Screw
20
Support Clip
21
SCREW
22
482731 Whirlpool Refrigerator Evaporator Fan Motor Kit
23
WP1100938 Whirlpool Refrigerator Fan Blade
24
WP487887 Whirlpool Refrigerator Screw
25
Grommet
26
WP488488 Whirlpool Refrigerator Screw
27
Baffle, Liner Top
29
Gasket, Sealing
30
Scroll, Fan
31
Cover, Evaporator
32
Gasket, Evaporator Cover
34
Control Panel, Meat Pan
35
Damper Control
36
Retainer, Spring
37
Control Knob
38
Seal, Control Panel
39
Damper, Foam Pad
40
WP489069 Whirlpool Compactor Screw
41
Grommet
42
Backup Plate
43
Seal, Control Panel
44
Liner (Not A Serviceable Part)
45
Socket
46
Shelf Stud, Saddle L.S.
47
WP488729 Whirlpool Refrigerator Door Screw
49
Shelf Stud Saddle (R.S.)
50
Hole Plug
52
Wiring, Ice Maker
53
RANGE ONLY 40W 120V APPL BULB
54
Light Lens
←
