LA450AXD3 02 – CABINET, TOP PANEL, BASE

Products

PositionProduct
1SCREW
2WCI 131374200
3WCI 5303208748
4WCI 131385900
55303208743 Frigidaire Grommet
6WCI 131374403
7134890500 Frigidaire Spring
9131390000 Frigidaire Door Catch-Strike
113204368 Frigidaire Screw-Strike
12134075500 Frigidaire Bumper-LID
13WCI 5303208751
14WCI 5308057419
153205821 Frigidaire Clip
165304505407 Frigidaire Cord
175303209428 Frigidaire Serv.Cord Bushing
18PIN – LOCATING
21WCI 5308014903
22WCI 5303161252
23WCI 3205414
24RETAINER
253204375 Frigidaire Check Valve
26WCI 5364154013
27131205100 Frigidaire Screw
28WCI 3204376
30WCI 5303010202
33134190200 Frigidaire Washer Water Valve
34131205500 Frigidaire Screw
35SNUBBER RING
36SHIPPING BLOCK
37SHIPPING SCREW
38WCI 5303300247
39134548800 Frigidaire Washer Leg Levelling
40PAD-LEG
41131302800 Frigidaire Drum Vane Screw
42WCI 131104305
433204374 Frigidaire Pin
46WCI 131062112
49131243800 Frigidaire Screw
50WCI 3205646
51WCI 3204391
52RIVET (3)
53WCI 131386214
54WCI 5303208778
56131422200 Frigidaire P-1 Self Level Leg Pad
