LA8580XWF0 04 – AGITATOR, BASKET AND TUB

LA8580XWF0 04 – AGITATOR, BASKET AND TUB

Written by

in

LA8580XWF0 04 – AGITATOR, BASKET AND TUB

Products

PositionProduct
163580 Whirlpool Washer Fabric Softener Dispenser
2WPW10074580 Whirlpool Agitator Inner Cap and Seal
3WPW10072840 Whirlpool Seal Assembly
4285811 Whirlpool Washer Agitator Repair Kit
580040 Whirlpool Washer Agitator Dog Kit
6WP3348752 Whirlpool Agitator Mover
7Seal, Agitator
8AGITATOR
9W10880720 Whirlpool Tub Ring
10WP3976308 Whirlpool Tub Seal
11W10389328 Whirlpool Basket
12WP21366 Whirlpool Spanner Nut
13285868 Whirlpool Washer Filter Plug Kit
143361596 Whirlpool Outer Tub Primary
15Lock, Filter
16WP389140 Whirlpool Drive Block or Bell
17W10814296 Whirlpool Washer Center Post Seal Gasket
18WP353244 Whirlpool Hose
19Hose, Bleach
20WP358237 Whirlpool Agitator Bolt
21WP596669 Whirlpool Hose Clamp
22285587 Whirlpool Thrust Washer
