LB5500XLW0 02 – TOP AND CABINET, LITERATURE AND OPTIONAL

LB5500XLW0 02 – TOP AND CABINET, LITERATURE AND OPTIONAL

Written by

in

LB5500XLW0 02 – TOP AND CABINET, LITERATURE AND OPTIONAL

Products

PositionProduct
1Nut, Push-In (2)
2Top (New Avocado)
2Top (White)
2Top (Almond)
2Top (Coffee)
2Top (Golden Harvest)
3WP62750 Whirlpool Spacer
5Cabinet (Almond)
5Cabinet (Coffee)
5Cabinet (White)
5Cabinet (New Avocado)
5Cabinet (Golden Harvest)
6WP62780 Whirlpool Cabinet Clip
7Screw & Washer
8Screw & Washer, Lid Switch (2)
9Harness, Lid Switch
10WP359231 Whirlpool Shield
11W10820036 Whirlpool Door Switch Kit
12Switch Actuator Assembly
13SCREW
14WP21097 Whirlpool Pad
15WP54584 Whirlpool Hinge
16WP91770 Whirlpool Hinge
17Bumper, Lid Hinge
18WP21258 Whirlpool Washer Lid Hinge Bearing
19Lid (Golden Harvest)
19Lid (New Avocado)
19Lid (Coffee)
19Lid (Almond)
19Lid (White)
20Strike, Lid Switch
22WP9724509 Whirlpool Bumper
23Handle, Lid (Coffee)
23Handle, Lid (Almond)
23Handle, Lid (White)
23Handle, Lid (New Avocado)
23Handle, Lid (Golden Harvest)
24Spring & Button, Lid ((L.H.))
25Plug, Button
26Stop, Push-In Top
27Bezel, Dispenser
28Almond (Uncut)
28Leveler (Thinner)
28WP72107 Whirlpool Touchup
28350572 Whirlpool Oil Transmission 15 Oz
28799344 Whirlpool Refrigerator Paint
2872017 Whirlpool Appliance Touch-Up Paint White
28WPL 383159
28350956 Whirlpool Spray Assembly
28WPL 383358
28350938 Whirlpool Spray Gun
28WPL 383449
2872110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz
28SCREW
28Golden Harvest
28WPL 799351
28Enamel, New Avocado (1 Qt. Uncut)
28Enamel, Coffee (1 Qt. Uncut)
2872109 Whirlpool Dacor Avocado Touch-Up Paint
28Paint, Spray 13 Oz. (Avocado)
28Guide, Laundry
28paint, spray 13 oz. (coffee)
28Paint, Touch-Up 1/2 Oz. (Coffee)
28Sheet, Installation Instructions
28WP285195 Whirlpool Sealer Assembly
28LUBRICANT (USE ONLY IN BRAKE SHOE ASSEMBLY ON ROLLER & PIN)
28Golden Harvest (Uncut)
28350930 Whirlpool White Spray Paint
